Tennis Nets & Posts

ACF Tennis Net by Edwards TM

Features Include

  • Heavy Duty Vinyl Coated Headband
  • 3.0mm braided polyethylene net body
  • Includes 7/8" diameter wooden dowels
  • Limited 3 Year Warranty
  • Net Length: 42'

ACF Sure Drop TM Internal Wind Net Posts

Specifications

  • Height: 57"
  • Inside Diameter: 2 1/2"
  • Outside Diameter: 2 7/8"
  • Yield Strength: 50,000 lbs. Minimum
  • Bending Strength: 34,890 lbs. Minimum
  • Color: Black or Green
  • Material: SS 40 Pipe with coating; all other components consists of aluminum, brass and/or stainless steel
  • Lacing Rod: Black Coated Steel attached with zinc coated TEK screws
  • Coating Caliper: GEN II Coating
  • Weight: 60 lbs.
  • Warranty: 5 Years against manufacturer defects

ACF Fast Drop TM External Wind Tennis Net Posts

(Posts shown above without crank)

Specifications

  • Height: 57"
  • Inside Diameter: 2 1/2"
  • Outside Diameter: 2 7/8" or 3 1/2"
  • Yield Strength: 50,000 lbs. Minimum
  • Bending Strength: 34,890 lbs. Minimum
  • Color: Black or Green
  • Material: SS 40 Pipe with coating; all other components consists of aluminum, brass and/or stainless steel
  • Lacing Rod: Black Coated Steel attached with zinc coated TEK screws
  • Coating Caliper: GEN II Coating
  • Weight: 60 lbs. or 64 lbs.
  • Warranty: 5 Years against manufacturer defects

Heavy Duty Tennis Post Crank

Specifications

  • Load Capacity: 900 lbs.
  • Gear Ratio: 3.1:1
  • Hub Diameter: 2"
  • Handle Length: 7"
  • Colors: Black, Green or Zinc Plated

Aluminum Tennis Post Crank

Specifications

All-aluminum parts are powder-coated green or black. The removable safety handle prevents net tampering. The reel fits most standard 2-7/8" outside diameter posts and includes screw for easy installation. The spring loaded cog cover gives a more positive lock as well as added safety for the user. Back plate measures 3 1/2" x 2 3/4"

ACF Anchor

Specifications

  • Material: Steel Conduit ? pressed & fluted on one end
  • Length: 10"
  • Diameter: 1"
  • Center Pin Material: Stainless Steel
  • Warranty: 1-year manufacturer's warranty

ACF Center Strap

Specifications

  • Center Strap Material: UV Treated Polyester Webbing
  • Center Strap Size: 2" Wide X 80" Long before manufacturing
  • Other Materials: Nickel-plated steel slide & swivel snap
  • Warranty: 1-year manufacturer's warranty
